Variabel Speed Drive ATV630D30N4 30kW Schneider
Schneider ATV630D30N4 30kW VSD adalah inverter/VFD industri dari Schneider Electric yang digunakan untuk mengatur kecepatan dan torsi motor AC 3-phase (380–480 V) dengan daya hingga 30 kW, terutama pada aplikasi proses seperti pompa, fan, dan HVAC; perangkat ini menawarkan efisiensi energi tinggi, kontrol motor yang fleksibel (asynchronous dan synchronous), serta fitur komunikasi terintegrasi seperti Ethernet dan Modbus untuk kemudahan integrasi ke sistem otomasi, sehingga cocok untuk industri yang membutuhkan performa stabil, hemat energi, dan monitoring cerdas.
Inverter Schneider
Variabel Speed Drive ATV630D30N4 30kW Schneider
| Range of product | Altivar Process ATV600 |
|---|---|
| Product specific application | Process and utilities |
| Product or component type | Variable speed drive |
| Variant | Standard version |
| Device short name | ATV630 |
| Mounting mode | Wall mount |
| Communication port protocol | Ethernet Modbus TCP Modbus serial |
| [Us] rated supply voltage | 380…480 V – 15…10 % |
| [Us] rated supply voltage | 380…480 V |
| Relative symmetric mains voltage tolerance | 10 % |
| Relative symmetric network frequency tolerance | 5 % |
| Nominal output current | 61.5 A |
| IP degree of protection | IP21 |
| Product destination | Asynchronous motors Synchronous motors |
| EMC filter | Integrated with 50 m conforming to IEC 61800-3 category C2 Integrated with 150 m conforming to IEC 61800-3 category C3 |
| IP degree of protection | IP21 conforming to IEC 61800-5-1 IP21 conforming to IEC 60529 |
| Degree of protection | UL type 1 conforming to UL 508C |
| Type of cooling | Forced convection |
| Supply frequency | 50…60 Hz – 5…5 % |
| Motor power kW | 30 kW (normal duty) 22 kW (heavy duty) |
| Motor power hp | 40 hp normal duty 30 hp heavy duty |
| Line current | 53.3 A at 380 V (normal duty) 45.9 A at 480 V (normal duty) 40.5 A at 380 V (heavy duty) 35.8 A at 480 V (heavy duty) |
| Continuous output current | 61.5 A at 4 kHz for normal duty 46.3 A at 4 kHz for heavy duty |
| Speed drive output frequency | 0.1…500 Hz |
| Safety function | STO (safe torque off) SIL 3 |
| Option card | Slot A: communication module, Profibus DP V1 Slot A: communication module, PROFINET Slot A: communication module, DeviceNet Slot A: communication module, Modbus TCP/EtherNet/IP Slot A: communication module, CANopen daisy chain RJ45 Slot A: communication module, CANopen SUB-D 9 Slot A: communication module, CANopen screw terminals Slot A/slot B: digital and analog I/O extension module Slot A/slot B: output relay extension module Slot A: communication module, Ethernet IP/Modbus TCP/MD-Link Communication module, BACnet MS/TP Communication module, Ethernet Powerlink |
