Inverter Solar Panel ICASolar SNV-GH2041 2kW48V
Penggunaan inverter Hybrid untuk mengubah arus DC dari panel surya menjadi arus AC. Inverter Solar Panel ICASolar SNV-GH2041 2kW48V Seperti sistem On-grid namun dapat menggunakan baterai untuk menyimpan listrik yang berfungsi sebagai cadangan listrik saat pemadaman.
Feature Highlights:
- Pure sine wave output
- Self-consumption and feed-in to the grid
- Programmable supply priority for PV, battery or grid
- User-adjustable charging current and voltage
- Programmable multiple operation modes: Grid-tied, off-grid and grid-tie with backup
- Monitoring software for real-time status display and control
- Parallel operation up to 9 units for 2kW/3kW/5kW models
- Battery independent system
Phase: 1-phase in/ 1-phase out
Max. PV input power: 3kW
Rated output power: 2kW
INPUT (DC)
Nominal DC Voltage/ Max. DC Voltage: 240Vdc/ 450Vdc
MPPT voltage range: 90Vdc~430Vdc
Number of MPP trackers/ Max. input current: 1/18A
GRID-TIED GRID OUTPUT (AC)
Nominal output voltage: 220/230/240Vac
Output voltage range: 184~264.5Vac or 195.5~253Vac (selectable)
Output frequency range: 47.5~51.5Hz or 49~51Hz (selectable)
Nominal output current: 8.7A
Power factor (cos Φ): >0.99
EFFICIENCY
Max. conversion efficiency (DC/AC): 95%
OFF-GRID & HYBRID OPERATION
AC INPUT
Acceptable input voltage range: 90~280Vac or 170~280Vac
Frequency range: 50Hz/60Hz (auto sensing)
Max. AC input current: 30A
BATTERY MODE OUTPUT(AC)
Nominal output voltage: 220/230/240Vac
Output wave form: Pure Sine Wave
Nominal output frequency: 50Hz
Efficiency (DC to AC): 93%
BATTERY & CHARGER
Nominal DC voltage: 48Vdc
Max. solar charging current: 60A
Max. AC charging current: 60A
Max. charging current: 60A
GENERAL
PHYSICAL
Dimensions (W*L*D) in mm: 120 x 295 x 468
Net weight: 11kg
INTERACE
Parallel function: Yes, 9 units
Communication port: USB or RS-232/ Dry contact
ENVIRONMENT
Humidity: 0~90% RH (no condensing)
Operating temperature: -10°C to 50°C
