Inverter Schneider Variable Speed Drive ATV21 4kW 5HP 480V ATV21HU40N4
perangkat variable speed drive (VSD) atau inverter seri Altivar 21 (ATV21)
Range dedicated to building HVAC aplications.
All essential functions for variable torque pump and fan applications:
- PI controller, preset PI
- Automatic restart, recovery on the fly
- Skip frequencies
- Belt breakage detection
- Overload detection and under load detection.
Frost & Sullivan 2008 European HVAC Electric Drives Technology Innovation Award
3-phase 200/240 V 380/480 V
- UL Type 1/IP20 and IP54 up to 75 kW.
- Speed range: 1:50.
- Overload: 110 % – 60 s.
- Integrated EMC filters class A or B.
- Main communication bus used on the building market: LonWorks, Metasys N2, BACnet, and Apologe FLN.
- Conformity to the international standards and certifications: CE, UL, CSA, C-Tick…
- “Reduced-Capacitance” technology: immediately operational and without harmful effect, harmonics treatment without added artifices: THDI < 30 %.
- Self-adaptation of ramps and motor control supply, to optimise energy consumption.
- Its remote terminal increases its user-friendliness: settings of the functions, configurations and parameter downloading and saving.
- Compact, side by side mounting.
- Motor and drive protection.
- Economical design.
Inverter Schneider Variable Speed Drive ATV21 4kW 5HP 480V ATV21HU40N4
| Range of product | Altivar 21 |
|---|---|
| Product or component type | Variable speed drive |
| Product destination | Asynchronous motors |
| Product specific application | Pumps and fans in HVAC |
| Assembly style | With heat sink |
| Component name | ATV21 |
| EMC filter | Class A EMC filter integrated |
| power supply voltage | 380…480 V – 15…10 % |
| Network number of phases | 3 phases |
| Motor power kW | 4 kW |
| Motor power hp | 5 hp |
| Line current | 6.4 A at 480 V 8.1 A at 380 V |
| Speed range | 1…10 |
| Transient overtorque | 120 % of nominal motor torque +/- 10 % for 60 s |
| Asynchronous motor control profile | Current flux vector control (FVC) without speed feedback Energy saving ratio Constant voltage/frequency ratio Quadratic voltage/frequency ratio Constant voltage/frequency ratio with automatic IR compensation |
| Communication port protocol | Modbus |
| Type of polarization | No impedance |
| IP degree of protection | IP20 on upper part without blanking plate on cover conforming to EN/IEC 60529 IP20 on upper part without blanking plate on cover conforming to EN/IEC 61800-5-1 IP21 conforming to EN/IEC 60529 IP21 conforming to EN/IEC 61800-5-1 IP41 on upper part conforming to EN/IEC 60529 IP41 on upper part conforming to EN/IEC 61800-5-1 |
| Option card | Communication card for APOGEE FLN Communication card for BACnet Communication card for LonWorks Communication card for METASYS N2 |
