Inverter Schneider Variable Speed Drive 22kW ATV61HD22N4
Schneider Altivar 61 ATV61HD22N4 adalah sebuah inverter (VFD/VSD) yang dirancang untuk mengendalikan kecepatan dan torsi motor listrik tiga fase pada sistem industri yang memakai motor ~22 kW pada tegangan jaringan 380–480 V AC tiga fase. Produk ini umum dipakai untuk aplikasi seperti pompa, kipas/ventilasi, kompresor, conveyor, dan sistem HVAC.
Inverter Schneider Variable Speed Drive 22kW ATV61HD22N4
| Range of product | Altivar 61 |
|---|---|
| Product or component type | Variable speed drive |
| Product specific application | Pumping and ventilation machine |
| Component name | ATV61 |
| Motor power kW | 22 kW, 3 phases at 380…480 V |
| Motor power hp | 30 hp, 3 phases at 380…480 V |
| power supply voltage | 380…480 V – 15…10 % |
| supply number of phases | 3 phases |
| Line current | 42 A for 480 V 3 phases 22 kW / 30 hp 50 A for 380 V 3 phases 22 kW / 30 hp |
| EMC filter | Level 3 EMC filter |
| Assembly style | With heat sink |
| Apparent power | 32.9 kVA at 380 V 3 phases 22 kW / 30 hp |
| maximum prospective line Isc | 22 kA for 3 phases |
| Maximum transient current | 57.6 A for 60 s, 3 phases |
| Nominal switching frequency | 12 kHz |
| Switching frequency | 1…16 kHz adjustable 12…16 kHz with derating factor |
| asynchronous motor control | Voltage/frequency ratio, 5 points Voltage/frequency ratio, 2 points Flux vector control without sensor, standard Voltage/frequency ratio – Energy Saving, quadratic U/f |
| Synchronous motor control profile | Vector control without sensor, standard |
| Communication port protocol | Modbus CANopen |
| Type of polarization | No impedance for Modbus |
| Option card | Communication card for APOGEE FLN Communication card for BACnet Communication card for CC-Link Controller inside programmable card Communication card for DeviceNet Communication card for EtherNet/IP Communication card for Fipio I/O extension card Communication card for Interbus-S Communication card for LonWorks Communication card for METASYS N2 Communication card for Modbus Plus Communication card for Modbus TCP Communication card for Modbus/Uni-Telway Multi-pump card Communication card for Profibus DP Communication card for Profibus DP V1 |
